Willis 3210-12 CNC Big Bore Lathe 220v
Have one to sell?
ConditionNew
1 available
New
Willis 32120-12 CNC Big Bore Lathe 220V
Includes 12” spindle bore (305mm), A2-20 mount, 4 – 600 RPM, back plate for Rear Chuck, Hydraulic tailstock
Since 1963, Willis Machinery and Tools has been a machine tool supplier, serving a wide variety of businesses throughout the world. With 60 years of providing products and services to businesses worldwide, Willis Machinery has become a very knowledgeable and respected supplier of CNC and conventional machinery.
As a member of The Association for Manufacturing Technology (AMT), Willis Machinery supplies a large number of machine tools to customers in Michigan, Ohio, Indiana, and Pennsylvania. Willis Machinery also serves a wide variety of businesses throughout the world with the help of authorized Willis machine tool dealers and direct salespeople.
- Fanuc 0i-TF PLUS control w/ Fanuc servo spindle, “manual guide i” software, and thread repair
- 12” spindle bore, A2-20 spindle nose
- Rear chuck adaptor with A2-20 spindle nose
- 30HP AC Digital Fanuc spindle motor, 100% duty
- 3-Step Spindle Speed
- 3 large sliding doors for front of machine
- 4 – 600 RPM
- Single chain type chip conveyor in rear
- Full Length Rear Splash Guard
- RS-232 Port
- (2) T-slots on top of crosslide
- Cutting Fluid Coolant System
- Working Lights for full work area
- Leveling Blocks, Service Tools & Toolbox
- Operation, Programming & Instruction Manuals
- 220-volt operation
• 30HP AC Digital Fanuc spindle motor, 100% duty
• 3-Step Spindle Speed
• 3 large sliding doors for front of machine
• Fanuc 0i-TF PLUS control w/ Fanuc servo spindle, “manual guide i” software, and thread repair
• 12” spindle bore, A2-20 spindle nose
• Rear chuck adaptor with A2-20 spindle nose
• Single chain type chip conveyor in rear
• Full Length Rear Splash Guard
• RS-232 Port
• (2) T-slots on top of crosslide
• Cutting Fluid Coolant System
• Working Lights for full work area
• Leveling Blocks, Service Tools & Toolbox
• Operation, Programming & Instruction Manuals
• 220-volt operation
Suggested Options
V8 electric turret, 1-1/4” square shank tools, includes (2) boring bar holders, (2) facing holders $15,340
Steady Rest (3” – 15”) $3,690
TOTAL AS STOCKED $310,590
ADDITIONAL AVAILABLE OPTIONS
Extra-large cross slide mounted boring bar holder with 100mm boring bar capacity $4,820
Aloris EA Q.C. tool post set w/ 4 holders for rear of cross slide $3,130
Steady Rest (15” – 25”) $6,110
Follow Rest $1,820
Hydraulic Tailstock included
Alternative voltages available $5,100
BISON BRAND CHUCKS
25” steel body 3 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $21,670
32” steel body 3 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $29,550
25” steel body 4 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $10,640
28” steel body 4 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $14,480
32” steel body 4 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $19,060
PRATT BURNERD BRAND CHUCKS
25” steel body 3 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $18,950
24” steel body 4 jaw chuck 12-1/2” hole, A2-20 mount, extra heavy duty $9,950
Specifications
Spindle motor, Fanuc AC Servo 30 HP
Swing over bed 31.5”
Swing over crosslide 20”
Center Height 15.7”
Distance between centers 118”
Bed width 22”
Cross slide width 12”
Z axis ball screw dimensions 63mm
Z axis travel 112”
X axis ball screw dimensions 40mm
X axis travel 21”
Tailstock quill taper 6 MT
Tailstock quill diameter 5”
Tailstock quill travel 10”
