NEW EVERISING Series H-1100HANC Automatic Band Saw with NC Control, Capacity 43.3"W: x 40"H (NEW; NOT IN STOCK)
Have one to sell?
ConditionNew
1 available
New
NEW EVERISING Series H-1100HANC Automatic Band Saw with NC Control, Capacity 43.3"W": x 40"H (NEW; NOT IN STOCK)
EVERISING has been specializing in mid to large size band saws and circular saws since 1982. Our R&D innovations have yielded constant break-through over the years. With two factories in Taichung, Taiwan, and another in Kunshan, China, yearly output is in excess of 2000 units. In Taiwan, sales offices are established in Taipei, Taichung, Tainan, and Kaohsiung. China has over ten branch offices and service centers throughout, providing complete pre-sales and after-sales services with full-scale sawing technology. Everising has more than forty sales distributors around the world, and our equipment can be found in over sixty countries worldwide.
Machine design suitable for using TCT saw blade.
Extreme Duty transmission.
Variable blade speed controlled by inverter.
Guide arm travels on linear guide way and moves in coordination with the movable vise jaw.
Auto trim cut and initial cut positioning.
Close approach vise reduces remnants.
Hydraulic full stroke dual-vise clamping system with floating vises.
PLC control, for all electric and hydraulic functions.
HMI/PLC User Friendly Touch Screen with selfdiagnosis system.
NC control with 9 working jobs.
Adjustable hydraulic pressure & feed control on control panel.
Power driven blade cleaning brush.
Automatic work height control by fast approach bar sensor.
Out of stock shutoff.
Blade anti-vibration device.
Hydraulic blade tensioning.
Idler wheel motion detector with blade stalling and breakage shutoff.
Hydraulic actuated carbide blade guides.
Roller type work table.
Independent electric cabinet and control panel.
Additional portable control panel.
Automatic chip conveyor.
Flushing hose for machine cleaning.
Work light.
One M42 bi-metal saw blade.
One set of tools and tool box.
Performance Specifications
Capacity ⬤ 27.5" ~ 40"
Capacity◼️ 31.5" × 27.5" ~ 43.3" × 40"
Minimum Clamping 15.7"
Index Length 20.0"
Blade Speed** (fpm) 50 ~ 250
Motor Blade Drive (hp) 15 HP
Blade Tension Hydraulic
Motor Hydraulic Pump (hp) 5 HP
Motor Coolant Pump (hp) 1/2 HP
Blade Size 437"× 3" × 0.063
Machine Weight 30,800 lbs
