2024 SENFENG Model 6024GNT Three Chuck Laser Tube Cutting Machine with Bevel Cutting, 0.39-9"
Have one to sell?
ConditionNew
1 available
New
2024 SENFENG Model 6024GNT Three Chuck Laser Tube Cutting Machine with Bevel Cutting, 0.39-9"
It can be used for bevel cutting of pipes in various applications, ensuring the sealing and safety of pipe connections, as well as improving structural strength and stability.
The Laser bevel tube cutting machine has superior performance, which can realize the bevel cutting of the pipe within the range of ±45°. It is equipped with 3D laser cutting head, which can easily cut H steel, I-beam, angle steel, channel steel and other profiles, as well as drop-shaped and concave shaped tubes. Compared with domestic pipe cutting machines of the same level, the processing range expand by 12%.
Model SF6024GT SF6035GT
Laser Power 3kW-6kW 3kW-6kW
Pipe Processing Range(Round Tube) φ10-φ230mm φ20-φ350mm
Pipe Processing Range(Square Tube) 10×10-230×230mm 20×20-245×245mm
Positioning Accuracy ±0.05mm ±0.05mm
Repeated Positioning Accuracy ±0.03mm ±0.03mm
Maximum speed of chuck 100r/min 75r/min
Maximum Speed 75m/min 80m/min
Maximum Acceleration 0.8G 0.6G
Table Maximum Load 250KG 1000KG
Power: 3,000 – 6,000 watts range (3kW-6kW)
Round Tube Diameter: Φ0.39″ -9″
Square Tube Length: 0.39″ *0.39″ -9″ *9″
Length of tubeing to be cut: 137.8" - 236.2"
Pipe Processing Range： 20’* φ0.39″~9.05″
(Square tube: 0.39″*0.39″~9.05″*9.05″)
Laser Power： 3000W/4000W/6000W
Maximum Speed： 246’/min
Maximum Load Weight： 374 lbs
Maximum Acceleration： 0.8G
X/Y Axis Positioning Accuracy： ±0.05mm
X/Y Axis Repeated Positioning Accuracy： ±0.02mm
Angle of Processing Bevel： ±45°
