TOS HULIN (Fermat) Vertical Boring Mill Model SKIQ 16 CNC 63" table, max work piece height 49.6"
Have one to sell?
ConditionNew
1 available
New
TOS HULIN (Fermat) Vertical Boring Mill Model SKIQ 16 CNC 63" table, max work piece height 49.6"
TOSHULIN, previously known as TOS Hulín, was founded in 1949 when construction of the plant got underway in the town of Hulín in what is now the Czech Republic. Initially, TOS Hulín was engaged in manufacturing a variety of machinery, but since 1951 the company has produced machine tools, eventually focussing production exclusively on Vertical Turning Lathes.
The TOSHULIN story is one of continuous innovation and improvement to our family of machines. In 1959, we manufactured our first vertical lathe with continuous working feed, numerically-controlled axes movements and tracing. This machine was built based on TOS Hulín’s proprietary design and was the first numerically controlled machine tool produced in Czechoslovakia, and also one of the first numerically controlled lathes in the world. In 1974, we introduced an innovative 15-position tool magazine for automatic tool exchange in the renowned SKIQ, which is still in demand and manufactured to this day.
In the ensuing years, TOSHULIN has been a constant technology leader in vertical lathes.
In 2019, TOSHULIN celebrated 70 years in operation. TOSHULIN has earned a reputation for excellence. We have installed more than 13,500 machine tools in more than 70 countries worldwide. Our target is to continue our cooperation with foreign partners and customers also in the future and to develop it even more.
Siemens Sinumerik 840D CNC Control
C-Axis
Full Enclosure
The machine is in good technical condition, under power, after agreement is possible to test it.
Machine is after complete overhaul and modernization by Fermat, 2023.
- regrinding of guide surfaces
- replacement of all rolling nests and washers, new wipers of guide surfaces
- disassembly of the main bearing - and complete overhaul of the bearing at the manufacturer
- inspection and replacement of other bearings, replacement of all ball screws and nuts
- repair of clamping plate (3 jaws chuck) - hydraulic- mechanical chuck of 120 degress plus 3 pcs of manual chucks
- new protective covers of the machine according current CE standarts including safety lock
- replacement of the lubrication system, incl. a new hydraulic unit
- new chip conveyor
- new water management (1000 liters)
- new Sinumerik 840 DSL control system with touchable rittal display OP 15 Black
- handwheel
- new Siemens main drive, new servomotors for X and Z axes
- new rotary encoder speed sensor, new power and signal cables for spindle motors
- new air conditioned electrical cabinet
- coolant pumps control of rotation of 15 position tool magazine via frequency converter
C axis including live tools with its speed in the range from 8 - 3300 rpm - via a two-speed Baruffaldi transmission
C axis one way positioning - strengthening units - positioning accuracy tolerance up to 10 angular seconds
Other options and accessories are mentioned more detailed in the offer on request
Control system Siemens Sinumerik 840D Sl
Max. diameter of workpiece 1800 mm (70.87")
Clamping diameter of rotary table 1600 mm (63")
Max. load of table 16000 kg (35,200 lbs)
Max. workpiece height 1260 mm (49.6")
Ram travel (Z) 1000 mm (39.37")
Ram size 180x200 mm (7.1" x 7.87")
Driven Tools YES
Number of tool positions (driven) 15(15)
Tool magazine YES
Number of positions in magazine 15
Speed driven tools 8 - 3300 /min
Power of driven tools 22 kW 25 HP
Vertical adjustment of traverse 800 mm (31.5")
Rotations of clamping plate 2 - 200 /min
Axis C 0.003 °
Main motor power 67 kW (75 HP)
