TFON Surfacer Deburring & Edge Rounding Machine, Model TF-RB 2510 Width: 39.37"
Punch, plasma, oxygen, laser etc. of metals such as steel sheet, stainless steel, galvanized sheet, aluminum sheet. It is used in the process of breaking the surface burrs and sharp corners formed after cutting. The main purpose of the Deburring and Edge Rounding machine is to reduce the labor force in manual activities such as flex and sandpaper, to use time more efficiently, to increase the quality of the work done, to clean the paint and material before assembly and to remove wastes such as paint and coating with the corner rounding process. ensures its destruction. At the same time, thanks to this machine, the possibility of manual labor and personal mistakes to cause work accidents is eliminated.
Punch, plasma, oxygen, laser, etc. of metals such as steel sheet, stainless steel, galvanized sheet, aluminum sheet.
It is used to remove the surface burrs and sharp edges formed after cutting.
The main purpose of the Deburring and Edge Rounding machine is to reduce the labor force in manual activities such as flex and sanding, to use time more efficiently, to increase the quality of the work done, to clean the material before painting and assembly, and to remove waste before paint and coating with the corner rounding process ensures its destruction. At the same time, thanks to this machine, the possibility of manual labor and personal errors causing work accidents is eliminated.
Tfon Surfacer® TF-RF 2510
Technical Specifications
Features Features
Material Steel, Aluminum And Stainless
Process Deburring, Edge Rounding
Material Thickness (mm) 0-120
Max. Material Width (mm) 1000
Min. Part Dimensions (mm) 50x50
Max Material Weight (kg) 500
Conveyor Speed (m/min) 0.6-4.0
Min. Deduster Need (m³/h) 4000
Machine Power - Power Consumption (kW) 12.7/20.2
Machine Weight (kg) 3000
Holder System Magnetic (Vacuum Optional)
Compressed Air Requirement Minimum 5,0 Bar
