KNUTH Fully Automatic Horizontal Miter Bandsaw 14" x 16" Capacity, 0-45 degrees mitering, Turkish manufacturer
Have one to sell?
$32,885.00 USD
ConditionNew
1 available
New
KNUTH Fully Automatic Horizontal Miter Bandsaw 14" x 16" Capacity, 0-45 degrees mitering, Turkish manufacturer.
The ABS 350 C is a robust fully automatic band saw designed for maximum reliability. The model impresses with high-quality components and a heavy, solid machine frame. The automatic feed via driven rollers in the clamping jaws enables continuous operation, perfect for single piece and series production. The angle cutting feature increases its versatility, allowing it to cover a wider range of applications.
Standard Equipment
Automatic band break control
Bundle vise
Coolant system
Hydraulic part clamping
Operating tools
Saw-band
Chip wiper
Feed roller table 47"
Operator instructions
Features
The ABS 350 C is a fully automated horizontal miter band saw for series production of solid materials, tubes, and profiles
In the vise integrated rollers feed the material
This efficient and cost-effective solution has a proven record, is very robust and provides precise cuts
The saw frame features excellent stability and vibration-damping characteristics, and can be rotated manually up to 45°
Very rigid adjustable carbide saw blade guide ensures high vertical angle accuracy
Saw blade stroke and workpiece clamping are hydraulically driven
Saw blade feed via micro-adjustable hydraulic valve
Switches and controls are conveniently arranged on a stand-alone control panel
The touchscreen allows for easy and convenient programming for fully automated operation
A motor with infinitely variable speeds transmits power via a continuous-operation idler gear to the blade drive wheel
The correct saw blade tension can be checked at the pressure gauge display
An automatic band breakage control, a high-performance coolant system, and an effective chip brush complement the standard equipment package
An additional roller conveyor and a Minimal Quantity Lubrication (MQL) system are available as options
Roller material feed vise for fully automatic operation
Angle cutting possibility for increased versatility
Facile operation via touchscreen
Height adjustment with switch to speed up the cutting process
Workpiece counter to facilitate continuous production
Manual top vise for bundle cutting
Specifications
Cutting Capacities
Cutting capacity 0°Round 14”
Flat (length x width): 16” x 14”
Square: 14”
Cutting capacity 30° Round: 13”
Flat (length x width): 16” x 14”
Square: 13”
Cutting capacity 45° Round: 13”
Flat (length x width): 11” x 12”
Square: 11”
Cutting speed: 65.4 fpm - 327 fpm
Drive Capacity
Motor rating main drive: 3 Hp
Motor rating hydraulic pump: 0.5 Hp
Motor rating feed: 0.3 Hp
Motor rating coolant pump: 0.2 Hp
Measures and Weights
Overall dimensions-length x width x height: 97” x 37” x 80”
Weight: 2,310 lbs.
Blade dimensions: 163.78” x 1.34” x 0.04”
Voltage: 230v 60Hz 3 phase
OPTIONS
253853 – 10 ft roller table for ABS 350 C
119950 – Bi-Metallic Band Saw Blade 3/4 T/"
119951 – Bi-Metallic Band Saw Blade 4/6 T/"
119952 – Bi-Metallic Band Saw Blade 5/8 T/"
253892 – Chip conveyor for ABS 350 C
253895 – Hydraulic saw blade tensioning for ABS 350 C
253851 – Micro spray cooling system for Band Saws 280-380
253753 – Laser pointer
253899 – Clamping force controlled at operator panel
103184 - Coolant Concentrate 5 Ltr
