FERMAT/LUCAS CNC Cylindrical Grinder MODEL BUC E 63/4000 CNC 24.8" X 157.5"

Description

FERMAT/LUCAS CNC Cylindrical Grinder MODEL BUC E 63/4000 CNC 24.8" X 157.5"
The FERMAT Group is one of the leading horizontal boring mill manufacturers. The history of the oldest Fermat member dates back to 1902. The production of machines is based on the tradition of manufacturing metal working and processing equipment in the region. Fermat employs experienced and skilled professionals and uses high quality components and materials. Hence the company reaches a high level of quality and precision and became one of the fastest growing producers of horizontal boring mills in Europe. Fermat sells its machines all around the world and participates at most renowned fairs. The company has about 530 employees and five production facilities in the Czech Republic. Despite the economic downturn Fermat manages to increase its production and reaches new emerging markets.
FERMAT occupies 29 500m2 (317 535 sq ft) production and assembly halls. The most important centers are situated in Prague and Brno (Prague 5300 m2/57 049 sq ft/ Brno 4800+ 3 600m2 / 38750 sq ft), the number of employees is currently about 535. The company sales soared despite the recent economic crisis. In the same period Fermat acquired several traditional manufacturers like Pressl Company in Pilsen and Strojtos Lipnik to increase the production facilities.

The BUC universal grinding machine is designed for external and internal grinding of workpieces clamped between the centers or clamped in the chuck. The feed-in of the grinding wheel head and the table are realized by servomotors and ball screws.
The BUC grinder is a very stable and precise machine that can be used in series production as well as in single-part production for workpieces up to 3 000 kg.

The machine grinds in working accuracy IT 4 and can be equipped with modern design features, as for example rolling bearing of the grinding spindle or hand scraping guideways with Teflon pads for minimal adhesion (stick-slip effect). In addition, the machine can be upgraded with an in-process gauge, axial probe, automatic (electric) steady rests, CNC rotary dresser, electric spindles, Z-axis encoder, etc.

The machine can be installed with, SINUMERIK 828D sl, SINUMERIK 840D sl, SINUMERIK ONE or FANUC control system.

The grinder is designed primarily for numerically controlled grinding of external cylindrical surfaces of various diameters and their neighbouring faces and radius. So called sweep cones may be ground by interpolation between axis X and Z. Grinding wheel head is mutually rotational. It enables vertical plunge-cut grinding using spindle swivel. This method may be particularly used for grinding steep cones and simultaneous grinding of cylindrical and face surfaces of workpieces. A folding device with a separate spindle is used for internal grinding.

In the special version, the machine is equipped with a C axis for precise positioning and grinding of non-circular shapes, a stiffer clamping work head or a polishing device for high surface quality. These superior features make the machine the most versatile and efficient solution on the grinding machines market.
