KENT INTERNATIONAL Model KGS-510WMA1 20" x 40" Surface Grinder, Downfeed Programmable
Have one to sell?
ConditionNew
1 available
New
KENT INTERNATIONAL Model KGS-510WMA1 20" x 40" Surface Grinder, Downfeed Programmable
W/ V & Flat “TURCITE” Ways; Hydraulic Table; PLC Controlled Cross-feed;
Auto Incremental Down-feed; Column Travelling Cross-feed;
Console Setting Cross-feed Travel; Re-Circulating Auto Lubricator;
Table Proximity Switches; New Style Enclosure Guarding; 10HP Spindle Motor
Auto Dressing and Auto Compensation.
KENT Industrial Co., Ltd. was built in 1966 with President Mr. C.S. Lu in Taiwan. Today, our company covers over 12,000 square meters and includes 200 staff members. Our main products are: surface grinders, CNC surface grinders, creep feed grinders, double column surface grinders, vertical machining centers, and double column machining centers. KENT Industrial Co., Ltd. sells machine tools worldwide to countries such as Brazil, Canada, England, France, Germany, Italy, India, Japan, Poland, Spain, USA and so on. KENT America office was opened in California, United States in 1979. Now, KENT International USA, Inc. is serving our customers in North and South America with excellent products and service.
Packaged With: Electro-Magnetic Chuck 20"x40"
With Console Built-In Variable Power Chuck Control;
Magnetic Separator & Paper Filter Coolant System; Parallel Dresser;
Automatic Cycle With Rough & Fine Feeding & Spark-Out time,
Retract Setting; PLC Cross-Feed Control; Servo Down-feed With
Ballscrew, Encoder & Manual Pulse Generator; Auto Dresser.
* New Mitsubishi Control & Touch-Screen Technology *
OPTIONAL EQUIPMENT
Magnetic Separator & Paper Filter Coolant System (M2)………. $ 4,450.00Extra Wheel Flange....................…………….................……………............................ $ 185.00Hydraulic Oil Cooler…………………………………........................................................,. $ 4,850.00
Table Splash Table Guard(Rear)……………………………................….. $ 100.00.
Full enclosure (top open)............................................................$ 9500.00
Full enclosure(top closed)……………………………………………………....... $ 11500.00
FEATURES & CAPABILITY
Longitudinal on V-flat scraped guideways
Column traveling cross-feed
Motorized rapid elevation
Spindle motor frequency inverter *Optional
Hydraulic oil chiller *Optional
Full enclosure *Optional
Overhead hydraulic wheel dresser
Variable spindle speed *Optional
Surface grinding
Plunge grinding
Specification Unit KGS-510WM Series
Capacity
Overall table working area INCH 20 x 40
Longitudinal table travel INCH 44.5
Cross-feed table travel INCH 21.3
Distance spindle center to table INCH 22.6
Rough Down-feed Increment:(Servo Drive) 0.00005”-0.0099”
Fine Down-feed Increment: (Servo Drive) 0.00005”-0.0099”
Spark-out Time Setting: 0-9 Times
MPG Resolution: 0.00005”/0.0005”
Grinding Wheel
Wheel dimension (Dia. x W x Bore) INCH 14 x 1.5 or 2 x 5
Spindle speed RPM 1,740
Vertical Movement
Vertical on MPG / Handwheel 1 gra INCH 0.00005
Vertical on MPG / Handwheel 1 rev INCH 0.005
Auto down-feed increment INCH 0.00005-0.01
Motor
Spindle motor HP 10
Dimension & Weight
Machine height INCH 95
Floor space INCH 175 x 83
Net weight LBS 11,000
Gross weight LBS 13,200
