KENT INTERNATIONAL Model KGS-618S Manual Surface Grinder 6" x 18"
Have one to sell?
ConditionNew
1 available
New
KENT INTERNATIONAL Model KGS-618S Manual Surface Grinder 6" x 18"
KENT Industrial Co., Ltd. was built in 1966 with President Mr. C.S. Lu in Taiwan. Today, our company covers over 12,000 square meters and includes 200 staff members. Our main products are: surface grinders, CNC surface grinders, creep feed grinders, double column surface grinders, vertical machining centers, and double column machining centers.
KENT Industrial Co., Ltd. sells machine tools worldwide to countries such as Brazil, Canada, England, France, Germany, Italy, India, Japan, Poland, Spain, USA and so on.
KENT America office was opened in California, United States in 1979. Now, KENT International USA, Inc. is serving our customers in North and South America with excellent products and service.
FEATURES & CAPABILITY
Longitudinal on Turcite-B coated and scrapped guideways
Down-feed on hardened and ground slideway
Cross-feed on Turcite-B coated and scrapped slideway
CXlass - 7 Paired & Pre-loaded Bearing Direct Drive Spindle
Halogen Work Light
6" x 18" Permanent Magnetic Chuck
KENT 2 Axis Digital Readout System
Wheel Balance Base & Arbor
Grinding Wheel
Wheel Flange
Table Dresser
Tool & Toolbox
Voltage In Stock 220v & 440/3/60 to be specified with P.O.
OPTIONS
Dust Collector & Coolant System $1,650 No Charge
Magnetic Separator & Coolant System $1,200 No charge
Extra Wheel Flange $ 65 No charge
Spindle motor frequency inverter *Optional
Overhead manual wheel dresser *Optional
Variable spindle speed *Optional
Surface grinding *Manual
Plunge grinding *Manual
Single slot grinding (between shoulders) *Manual
Profile wheel dressing *Manual (Optional)
MAIN SPECIFICATIONS
Specification Unit KGS-618S
Capacity
Overall table working area INCH 6" X 18"
Longitudinal table travel INCH 18.7"
Cross-feed table travel INCH 7.3"
Distance spindle center to table INCH 15"
Grinding Wheel
Wheel dimension (Dia. x W x Bore) INCH 7 x 0.8 x 1.27
Spindle speed RPM 3360
Vertical Movement
Vertical on MPG / Handwheel 1 gra INCH 0.005
Vertical on MPG / Handwheel 1 rev INCH 1
Motor
Spindle motor HP 2
Dimension & Weight
Machine height INCH 79
Floor space INCH 71 X 47
Net weight LBS 1,540
Gross weight LBS 1,870
