KSI SWISS MODEL TCM 32S SWISS TYPE AUTOMATIC
Have one to sell?
ConditionNew
1 available
New
KSI SWISS MODEL TCM 32S SWISS TYPE AUTOMATIC
KSI Swiss provides the highest quality world-class Swiss Style Automatic CNC Lathes offered today. KSI Swiss, in partnership with an engineering company, machine tool builder, we're the only American owned provider of this type of machine tool. KSI is a family operated company with USA Headquarters located in Minnesota. You will not find a better value anywhere. The KSI Swiss machines are known for their 'more' factor, more mass, more rigidity, more tools, more stroke, more thrust, more included options, more training, more room, more profits etc. Put our machine against any competition, and you will see that what we have to offer, is the best value on the market. We listen carefully to what our customers say, and use their feedback to help make our products better. We're constantly striving to improve our products, as well as add new products as demand rises.
Intelligent Chucking
G300 re-chuck optimization
High precision mode (M100)
Rapid tool change (RTC)
Variable frequency turning (VFT)
Software controlled tool breakage detection
On screen G code list
On screen M code list
LED Red/Yellow/Green Signal Light
Parts Chute
Parts Conveyor
Sub Spindle Work Ejector
Cutting Oil Tank and Chip Pan are removable and independent
200L Cutting Oil Tank
Main coolant pump flow sensor
Sub-coolant pump (optional)
Automatic Power-Off
M97 - Parts counter
Work-dual zone LED Lighting
M86 - Cut off tool breakage detector software
Tool life management system
Collision prevention system
Sub spindle Air Blow (thru sub- spindle long shaft ejection ready)
Pre-Wired for Main Coolant, Pre-Wired for Sub Coolant
Pre-Wired for Chip Conveyor, Pre-Wired Flow Sensor
(4) M codes for High Pressure Coolant system
(2) M codes for application (Electric spindle/HP coolant)
M108/M109 - Additional secondary coolant pump
Automatic waylube system
Z1 Axis Stroke 11.81"
Z2 Axis Stroke 11.81"
X1 Axis Stroke 2.44"
Y Axis Stroke 15.41"
X2 Axis Stroke 15.94"
Spindle Hole Dia 1.25"
Sub Spindle Bore 1.25"
Number of tool stations 27
Main Side 18
Ball Screw Diameter .98"
LM Guide Mfger Bosch Rexroth
Max Sub Spindle Speed 8,000 RPM
Sub Spindle HP 3 HP
Power 10 HP
RPM 10,000 RPM
# Axis 7
Control CNC (Fanuc OTiF)
Dimensions 107" X 59" X 71"
Weight 7,725 Pounds
