KENT INTERNATIONAL SINGLE AXIS AUTOMATIC SURFACE GRINDER KGS-618H
Have one to sell?
ConditionNew
1 available
New
KENT INTERNATIONAL SINGLE AXIS AUTOMATIC SURFACE GRINDER KGS-618H
KENT Industrial Co., Ltd. was built in 1966 with President Mr. C.S. Lu in Taiwan. Today, our company covers over 12,000 square meters and includes 200 staff members. Our main products are: surface grinders, CNC surface grinders, creep feed grinders, double column surface grinders, vertical machining centers, and double column machining centers.
KENT Industrial Co., Ltd. sells machine tools worldwide to countries such as Brazil, Canada, England, France, Germany, Italy, India, Japan, Poland, Spain, USA and so on.
KENT America office was opened in California, United States in 1979. Now, KENT International USA, Inc. is serving our customers in North and South America with excellent products and service.
V & Flat TURCITE Table Ways; Hydraulic Table
Double -V TURCITE Cross Ways
Cast Iron Base; Re-settable Longitudinal Handwheel
Large Down-feed Graduation Dial; Cross-feed Locking Mechanism
Class-7 Paired & Pre-Loaded Bearing Direct-Drive Spindle
Halogen Lamp; Standard 220/440 Voltage
Includes: 6" x 18" Permanent Magnetic Chuck & KENT 2 Axis DRO system
OPTIONAL EQUIPMENT
Dust Collector & Coolant System $1,490.00
Coolant System (Factory Order) $ 880.00
Extra Wheel Flange $ 60.00
MAIN SPECIFICATIONS
Specification Unit KGS-618H
Capacity
Overall table working area 6" x 18"
Longitudinal table travel 18 5/8"
Crossfeed table travel 7 1/4"
Distance spindle center to table 15"
Parallelism & Flatness Accuracy 0.0002"
Grinding Wheel
Wheel dimension (Dia. x W x Bore) 7" x 1/2" x 1 1/4"
Spindle speed 3,360
Vertical Movement
Vertical on MPG / Handwheel 1 grad 0.005
Vertical on MPG / Handwheel 1 rev 1
Motor
Spindle motor 2 HP
Dimension & Weight
Machine height 79"
Floor space 71" x 47"
Net weight 1,540 lbs
Gross weight 1,870 lbs
