KENT INTERNATIONAL MANUAL SURFACE GRINDER MODEL KGS-616S 6" x 16"
KENT Industrial Co., Ltd. was built in 1966 with President Mr. C.S. Lu in Taiwan. Today, our company covers over 12,000 square meters and includes 200 staff members. Our main products are: surface grinders, CNC surface grinders, creep feed grinders, double column surface grinders, vertical machining centers, and double column machining centers.
KENT Industrial Co., Ltd. sells machine tools worldwide to countries such as Brasil, Canada, England, France, Germany, Italy, India, Japan, Poland, Spain, USA and so on.
KENT America office was opened in California, United States in 1979. Now, KENT International USA, Inc. is serving our customers in North and South America with excellent products and service from offices in Elk Grove Village, IL and warehouse in Elgin, IL.
FEATURES & CAPABILITY
KENT 2 Axis Digital Readout
Longitudinal on ball bearing table ways
Downfeed on hardened and ground slideway
Crossfeed on Turcite-B coated and scrapped slideway
Downfeed Microfeed Mechanism
Crossfeed Microfeed Mechanism
Spindle motor frequency inverter *Optional
Overhead manual wheel dresser *Optional
Variable spindle speed *Optional
Surface grinding *Manual
Plunge grinding *Manual
Single slot grinding (between shoulders) *Manual
Profile wheel dressing *Manual (Optional)
OPTIONS
6”x14” Permanent Magnetic Chuck
Dust Collector & Coolant System
Magnetic Separator & Coolant System
Extra Wheel Flange
2-axes Digital Read-Out System
DRO Installation & Display Arm & Tray, Mounting Bracket(Two Axes)
Specification Unit KGS-616S
Capacity
Overall table working area 6" x 16"
Longitudinal table travel 16.9"
Crossfeed table travel 7.9"
Distance spindle center to table 17.3"
Grinding Wheel
Wheel dimension (Dia. x W x Bore) 8"x3/4"x1 1/4"
Spindle speed 3,480
Vertical Movement
Vertical on MPG / Handwheel 1 grad 0.00005"
Vertical on MPG / Handwheel 1 rev 0.1"
Motor
Spindle motor 2 HP
Dimension & Weight
Machine height 68"
Floor space 64" x 48"
Net weight 1,380 lbs
Gross weight 1,650 lbs
