MODEL KGS-616S
Have one to sell?
ConditionNew
1 available
New
MODEL KGS-616S
FEATURES & CAPABILITY
Longitudinal on ball bearing table ways
Downfeed on hardened and ground slideway
Crossfeed on Turcite-B coated and scrapped slideway
Downfeed Microfeed Mechanism
Crossfeed Microfeed Mechanism
Spindle motor frequency inverter *Optional
Overhead manual wheel dresser *Optional
Variable spindle speed *Optional
Surface grinding *Manual
Plunge grinding *Manual
Single slot grinding (between shoulders) *Manual
Profile wheel dressing *Manual (Optional)
MODEL KGS-616S
OPTIONS
6”x14” Permanent Magnetic Chuck
Dust Collector & Coolant System
Magnetic Separator & Coolant System
Extra Wheel Flange
2-axes Digital Read-Out System
DRO Installation & Display Arm & Tray, Mounting Bracket(Two Axes)
MODEL KGS-616S
MAIN SPECIFICATIONS
Specification Unit KGS-616S
Capacity Overall table working area
Longitudinal table travel
Crossfeed table travel
Distance spindle center to table INCH
INCH
INCH
INCH 6 x 16
16.9
7.9
17.3
Grinding Wheel Wheel dimension (Dia. x W x Bore)
Spindle speed INCH
r.p.m 8 x 3/4 x 1 1/4
3480
Vertical Movement Vertical on MPG / Handwheel 1 gra
Vertical on MPG / Handwheel 1 rev INCH
INCH 0.00005
0.1
Motor Spindle motor HP 2
Dimension & Weight Machine height
Floor space
Net weight
Gross weight INCH
INCH
LB
LB 68
64 x 48
1380
1650
