KENT International 3-Axes Automatic Precision Surface Grinder Model KGS-620AHD, Capacity 26"W x 87.7"L
Have one to sell?
ConditionNew
1 available
New
KENT International 3-Axes Automatic Precision Surface Grinder Model KGS-620AHD ( 3 Axes Automatic ). Capacity 26"W x 87.7"L
KENT (Kent Industrial Co., Ltd. in Taiwan and Kent International USA) is a manufacturer with history of 50 years and the very first Taiwanese grinder manufacturer. Producing more than 125,000 grinders since the beginning. KENT makes own spindles, magnetic chucks, and hand scraping guideways. These are key components for keeping high-quality of grinders. As a manufacturer, KENT controls the design, spec and quality in-house and always supports customers with responsive service and parts supply.
FEATURES & CAPABILITY
Longitudinal on V-flat scraped guideways
Column traveling crossfeed
Motorized rapid elevation
Spindle motor frequency inverter *Optional
Hydraulic oil chiller *Optional
Full enclosure *Optional
Overhead hydraulic wheel dresser
Variable spindle speed *Optional
Surface grinding
Plunge grinding
W/ V & Flat “TURCITE” Ways; Hydraulic Table;
Auto Incremental Down-feed; Column Traveling and Console Setting Cross-feed;
Re-Circulating Lubricating System; Table Proximity Switches;
Full Length Rear Splash Guard; Halogen Light.
OPTIONAL EQUIPMENT
Magnetic Separator & Paper Filter Coolant System (M4)………..……... $ 3,500.00
Extra Wheel Flange................................................................................. $ 250.00
Single Axis DRO System with Display (LH70 + GB60ER)…………......... $ 2,320.00
Two Axes DRO System with Display (LH70 + GB75ER)……………....……$ 2,820.00
Hydraulic Oil Cooler………………………………………………...........................…… $ 6,500.00.
Table Splash Guard (Rear)………………………………………………......................… $ 100.00
Upgrade to Fine Pole Electro Magnetic Chuck…………………........……….. $13,000.00
W/ V & Flat “TURCITE” Ways; Hydraulic Table;
Auto Incremental Down-feed; Column Travelling and Console Setting Cross-feed;
Re-Circulating Lubricating System; Table Proximity Switches;
Full Length Rear Splash Guard; Halogen Light.
Packaged With: 24”x80” Electro-Magnetic Chuck
With Console Built in Variable Power Chuck Control;
Magnetic Separator Coolant System (M2); Hydraulic Parallel Dresser.
MAIN SPECIFICATIONS
Max. Travel (Longitudinal x Cross): 87-3/8"x26-3/8"
Max. Distance Spindle Center to Table: 23-5/8"
Down-feed Increment:( in 6 steps) 0.0002"-0.0016"
Grinding Wheel (OD. x T. x ID.): 14"x2"x5"
Grinding Wheel Speed: 1740rpm
Spindle Motor: 10HP (220/440/60/3)
Hydraulic Motor: 5HP (220/440/60/3)
Machine Net Weight: 20240 LBS
Packing Dimension: 181”x90”x99”
