Willis BTM60 CNC Milling Machine w/ Fagor 8058i Control In stock
Have one to sell?
ConditionNew
1 available
New
Willis BTM 60 CNC Milling Machine w/ Fagor 8058i Control In stock
Willis BTM-60 3-axis Bed Type Mill with 10HP programmable spindle speed,
60 - 4,000 RPM with 2 gear ranges,
24” x 73” table, 2600 lb. table load capacity,
60” x 30” x 27” X-Y-Z travel
CNC BED MILL MODEL BTM 60
All of our CNC bed mills are designed and constructed using the latest technology, and are built from the highest quality materials and components available.
“Willis” Bed Mills feature a rigid meehanite cast base, column, and saddle. These vertical travel CNC mills utilize wide, ground, and hardened ways (not linear), providing maximum rigidity and load bearing characteristics. Turcite coats the adjacent way surfaces.
A metered, automatic lubrication system with low-level alarm provides oil to the CNC machine’s slide ways, as well as, to the X, Y, and Z ball screws.
Oversize, high precision ball screws are mounted in precision bearings, ensuring long life, superior cutting performance, and great accuracy from our CNC bed mills.
Our BTM series CNC bed mills are offered with a 2-piece rear splash guard, chip pan, and steel telescoping way covers. An optional table mounted splash guard with sliding doors is also available on these CNC mill machines for sale.
The mill head is equipped with a high/low gear range for maximum power and torque throughout the entire spindle speed range. The spindle motor is equipped with an AC digital “Yaskawa” inverter drive for peak performance.
A flood coolant system is standard equipment on the Willis CNC VMC.
The mill head tilts 90° left and right maintaining its rigidity from front to back.
The CNC bed mill's column is thick and ribbed for maximum rigidity. Our CNC vertical bed mills also provide an extra long bolster in order to support the head’s rigidity.
The “Fagor 8058” CNC control includes, conversational programming and G-code conversion capabilities.
Included Option Package:
• Chip/coolant pan
• Column mounted rear splashguards
• Steel telescoping front bed way cover
• Steel telescoping rear bed way cover
• Maxi Torque-Rite power drawbar
• Halogen work light
Control includes the following; 8058i MC CNC Control
3-Axis System – 4th Axis Ready
3 Axis Simultaneous
Connectivity using TeamViewer software
Solid Graphics
Offline programming software
USB Connection
LCD color monitor
Ethernet
Emergency Switch
Operating Modes- Manual Mode / Two Axis CNC Mode
Programming: ICON based Conversational / G-Code
Customizable Screen Display
Surface UFO Hand Wheel
Brake on Z axis servo motor
System Enclosures: Operator Enclosure (17x17x6) / Electronic Enclosure (30x24x10)
Fully Assembled and Tested
AC frequency inverter and braking resistor for infinitely variable spindle speed through controller
Machine Standard Features:
• 60” x 30” x 28” X, Y, and Z travels
• 32” + maximum distance from spindle nose to table
• 73” x 24” hardened and ground table surface
• Hardened and ground box ways for the bed and column with Turcite on opposing bearing surfaces and gibs
• Programmable spindle speeds through Fagor Control
• 60 - 4,000 infinitely variable spindle speed with 2 gear ranges for optimum power and torque
• Mill head is capable of being tilted up to 90 degrees to the right or left
• 40-taper spindle or NMTB
• 6” manual quill travel
• 4 1/8” quill diameter
• Automatic lubrication system with metered valves
• 3 axes high precision ball screws supported at both ends for maximum accuracy
• Counterbalance for milling head
• High quality Meehanite castings
• 3,300 lbs. table load capacity (centered)
• Telescoping cover for Z axis ball screw
• Flood coolant controlled by M functions through Fagor Control
Optional Accessories (Installed Price):
Table mounted splashguard $ 1,500.00
6” vise $ 390.00
On-site training and start up $ 960.00 / day + expenses
FEATURES
60” x 30” x 28” X, Y, and Z travels
Up to 36” maximum distance from spindle nose to table
73” x 24” hardened and ground table surface
Hardened and ground box ways for the bed and column with turcite on opposing bearing surfaces and gibs
Programmable spindle speeds through Fagor Control
60 - 4000 infinitely variable spindle speed with 2 gear ranges for optimum power and torque
Mill head is capable of being tilted up to 90 degrees to the right or left
40 taper spindle
6” manual quill travel if needed, or quill can be extended out the mill head for machining in deep pockets if needed
4 1/8” quill diameter
Automatic lubrication system with metered valves
3 axes high precision ball screws supported at both ends for maximum accuracy
Counterbalance for milling head
High quality Meehanite castings
2,600 lb table load capacity (centered)
Telescoping cover for Z axis ball screw
Flood coolant controlled by M functions through Fagor Control
