FERMAT/LUCAS Table Type Horizontal Boring Mill Model WFT R 15 CNC Spindle Diameter 5.91" X axis 157.5" x Y axis 98.5"
Have one to sell?
ConditionNew
1 available
New
FERMAT/LUCAS Table Type Horizontal Boring Mill Model WFT R 15 CNC Spindle Diameter 5.91" X axis 157.5" x Y axis 98.5"
FERMAT began in 1990 and was founded by Jiří Ferenc and Mr. Matys, whose last names were used to form the company name. From the outset, FERMAT has benefited from the solid professional ethics of family and friends to guide its excellence. Through strong growth and strategic acquisitions in the Czech Republic and the United States, FERMAT has become the leading manufacturer of the most powerful and accurate horizontal boring and milling machines and cylindrical grinding machines, providing machine tools for all major markets worldwide.
Today, FERMAT has more than 470 employees on three continents, producing more than 100 machines a year. FERMAT's main production and assembly facilities are in Brno, the second largest city of Czechia and Lipnik and Becvou, to the north-east. As FERMAT continues to expand its machine tool range, this capital expansion will continue.Most popular FERMAT table-type horizontal boring mill, for high-performance machining with maximum utilization of accessories and automatic milling heads for efficient machining of workpieces of up to 20 tons.
Spindle diameter 130 mm or 110 mm; spindle travel 800 mm.
Optional ram stroke 700 mm.
Powerful and precise milling, coordinate drilling, boring, and threading.
Extremely versatile series of table-type horizontal boring mills, fully compatible with a wide range of accessories and automatic milling heads.
The machine WFT 15 is a table-type boring mill, with spindle diameter of 150 mm. As a standard, it is equipped with rotary table with load capacity 20 tons. But in this way, the machine for customer SMS was quite special. It was not with one table, but with two with maximum load 25 tons - a full-scale palletisation system. On one table you can do the machining, while clamping new workpiece on the other. This system reduces downtime of the machine and makes production more effective. Of course, as with any other patellisation system, the area for exchanging workpieces needs to be separated from machining area.
Optional
Universal Automatic Milling Head High Speed.
Fully Automatic (attachment to the headstock, tool clamping, positioning, lubrication).
Positioned by the means of 2 x 2 servomotors (in MASTER-SLAVE preloading), enables continuous machining.
Special Head UHAmi SDHS
Revolutions rpm 10-5000
Max. Power &@ HP
Max. Torque Nm 1500
Spindle Taper - SK 50
Clamping Force of Tool kN 20±15%
For head:
External Tool Coolant: standard
Coolant Trough Spindle: standard
Lubrication: automatic, oil
Table travel - X-axis: 157.48"
Headstock travel - Y-axis: 98.43"
Column travel - Z-axis: 59.0"
Spindle travel - W-axis: 31.5"
Ram travel - V-axis: 27.56"
Spindle diameter: 5.91"
Max. spindle speed: 2,800 RPM
Table plate size: 70.87" x 86.6"
Table load: 44,000 lbs
Max. power: 60 HP
Max. torque: 2713 Nm
Control system: FANUC
Available: Immediately
