KENT International USA 3 Axes Automatic 8" x 18" Surface Grinder Model KGS-250AHD
Have one to sell?
ConditionNew
1 available
New
KENT International USA 3 Axes Automatic 8" x 18" Surface Grinder Model KGS-250AHD
KENT Industrial Co., Ltd. was built in 1966 with President Mr. C.S. Lu in Taiwan. Today, our company covers over 12,000 square meters and includes 200 staff members. Our main products are: surface grinders, CNC surface grinders, creep feed grinders, double column surface grinders, vertical machining centers, and double column machining centers.
KENT Industrial Co., Ltd. sells machine tools worldwide to countries such as Brazil, Canada, England, France, Germany, Italy, India, Japan, Poland, Spain, USA and so on.
KENT America office was opened in California, United States in 1979. Now, KENT International USA, Inc. is serving our customers in North and South America with excellent products and service.
D-2 Hardened & Ground Ball Bearing Table Ways
Hydraulic Driven, Ball Bearing Table Ways (X Axis)
Double-V Turcite Cross Ways (Z Axis
8” X 18” Electic Magnetic Chuck w/Chuck Control
Class-7 Paired & Pre-loaded Bearing Spindle Cast Iron Base
Halogen Work Light
“KENT” 2 Axis Digital Read-Out System
Vernier Down-feed Graduation Dial
Magnetic Separator or Paper Filter Coolant System (Specify with Purchase Order)
Over Head Parallel Dresser
Solid State Controlled Cross- Feed
Auto Incremental Down-feed
Full Length Rear Splash Guard
Auto Incremental Down-feed
Wheel Balancing Base & Arbor
Grinding Wheel
Table Dresser
Wheel Flange
Tools & Tool Box
KGS-250AHD
Capacity
Overall table working area: 8" x 18"
Longitudinal table travel : 21.25"
Cross-feed table travel : 10.5"
Distance spindle center to table : 18.6"
Grinding Wheel
Wheel dimension (Dia. x W x Bore) : 8" x 3/4" x 1 1/4"
Spindle speed : 3,480 RPM
Vertical Movement
Vertical on MPG / Handwheel 1 gra : 0.0005"
Vertical on MPG / Handwheel 1 rev : 0.1"
Auto down-feed increment : 0.0001-0.001"
