KENT International USA Saddle Type Surface Grinder KGS-84AHD 16" x 32"
Features & Capability
Longitudinal on V-flat scraped guideways
Saddle traveling crossfeed
Motorized rapid elevation
Spindle motor frequency inverter *Optional
Hydraulic oil chiller *Optional
Full enclosure *Optional
Overhead hydraulic wheel dresser
Variable spindle speed *Optional
Surface grinding
Plunge grinding
Options at Additional Cost
Magnetic Separator & Paper Filter Coolant System (M2)
Digital Read Out System
DRO Installation & Display Arm & Tray, Mounting Bracket
Fine Pole Electromagnetic Chuck
Extra Wheel Flange
Table Splash Guard (Rear)
Full Enclosure Guarding
Spindle Motor Frequency Inverter for Variable RPM
Hydraulic Oil Chiller
Worktable are 31.5" x 15.75"
Longitudinal table travel 36.25"
Cross feed table travel 17.72"
Distance from spindle center to table 23.62"
Table load including magnetic chuck 27.56"
T-slot .55" x 3 N
Longitudinal table feed 5-25 m/min
Power cross feed 1000/1200 mm/min (50 Hz/60 Hz)
Hand wheel cross feed: 0.02mm (1 gra); 5mm ( 1 rev)
Auto cross feed per stroke 0.25-20 mm
Spindle motor 7.5HP
Coolant motor 190 W
