KENT International USA Programmable Rotary Surface Grinder KGR-600R, 2 Axes Programmable
Have one to sell?
ConditionNew
1 available
New
KENT International USA Programmable Rotary Surface Grinder KGR-600, 2 Axes Programmable
FEATURES & CAPABILITY
Cross Roller Bearing Table
2-axis Precision Roller Linear Guides
2-axis Precision Ballscrew and Servo Motor Driven
Mitsubishi Color Touch Screen and Tech Interface
Variable Spindle and Table RPM
Tapered Surface Grinding
Auto Dress and Auto Compensation
Auto Wheel Balancer *Optional
Packaged With: Electro-Magnetic Chuck (Diameter 39.4”) W/ Console Built-In Variable Power Chuck Control; Magnetic Separator & Paper Filter Coolant System; Automatic Cycle with Rough & Fine Feeding & Spark-Out time; Retract Setting; Encoder & Manual Pulse Generator; Spindle Motor Frequency Inverter; Table Mounted Wheel Dresser.
* Advanced Mitsubishi PLC Control & Touch-Screen Technology *
STANDARD EQUIPMENT
Wheel Balancing Base x 1pc Wheel Balancing Arbor x 1pc
Grinding Wheel x 1pc Wheel Flange x 1pc
Table Dresser x 1pc Tool Box & Tools x 1se
Specification Unit KGR-500
Capacity
Table diameter INCH 19.6
Max cross travel INCH 15.7
Distance spindle center to table INCH 23.6
Max table load LBS 1322
Table
Table speed INCH 10-100
Crossfeed MPG x1, x10 1 gra. INCH 0.00005/0.0005
Crossfeed MPG x1, x10 1 rev. INCH 0.005/0.05
Crossfeed auto increment INCH 0.0005-1
Wheel
Spindle speed RPM 0-1,800
Wheel dimension (Dia. x W x Bore) INCH 16 X 3.1 X 5
Elevation
Elevation in-feed MPG x1, x10 1 gra. INCH 0.00005/0.0005
Elevation in-feed MPG x1, x10 1 rev. INCH 0.005/0.05
Auto downfeed increment INCH 0.00005-2.5
Motors
Spindle motor HP 10
Weight & Dimension
Floor space INCH 90.5 X 126 x 104.3
Net weight LBS 11,023
Gross weight LBS 12,126
