KENT International USA 3 Axes Automatic Precision Surface Grinder KGS-63AHD
Have one to sell?
$33,800.00 USD
ConditionNew
1 available
New
KENT International USA 3 Axes Automatic Precision Surface Grinder KGS-63AHD
V & Flat Turcite Table Ways; Hydraulic Table; Solid State Control Cross-feed;
Double-V Turcite Cross Ways; Auto Lubricating Pump; Auto Incremental Down-feed;
Fully Automatic Cycle Control with Spark-Out & Auto Stop.
1. Well designed cast iron structure provides
excellent dampening.
2. The ball bearing slide ways ensure smooth and
easy operation.*
3. Hand-scraped Turcite ways guarantee long
lasting performance.**
4. Automatic lubrication pump for guide ways
and leadscrews.(1020AHD, 63AHD, 84AHD).
5. Automatic down-feed gearbox for accurate
down-feed increments (AHD models).
6. Low voltage safety control panel with a
separate electric cabinet.
7. Cartridge type spindle with high precision,
preloaded angular contact ball bearings.
8. Separate hydraulic tank prevents heat and
vibration from being transferred to the
machine (AHD models).
12”x24” Electric Magnetic Chuck With “Kent” Chuck Control;
Full Length Rear Splash Guard; Two Front Table Splash Guard; Over
Head Parallel Dresser; Magnetic Separator & Coolant System;
Halogen Light.
Standard Equipment
Wheel Balancing Base x 1pc Wheel Balancing Arbor x 1pc
Grinding Wheel x 1pc Wheel Flange x 1pc
Table Dresser x 1pc Tool Box & Tools x 1set
Max. Travel (Longitudinal x Cross):……………………. 27-15/16"x13-3/8"
Max. Distance Spindle Center To Table:……………….. 24"
Automatic Down-feed Increment:……………………….. .00025” to .00125” in 5 steps
Grinding Wheel ( OD x T x ID ):………………………… 14"x1-1/2"x5"
Grinding Wheel Speed:…………………………………. 1740rpm
Spindle Motor:…………………………………………. 7.5HP (220/440/60/3)
Hydraulic Motor:………………………………………. 2HP (220/440/60/3)
